Org-capturing live Jira Issues
Published 2022-05-08

Problem Statement

In my job, we use Atlassian Jira to manage and track our work. The main thing I interact with in Jira are "issues" ("tickets" in other services): I have a handful or two in flight at any given time. When I work on issues, I take extensive notes on them in a single Org file that I maintain for my job.

I create a new Org TODO heading for an issue, and continue to work with that heading frequently enough to justify investing time into automating the heck out of it.

What I ended up with is a very lightweight integration of Org and Jira that helps with pulling an issue's metadata from Jira's API into an Org heading, and with keeping it current in there over time1.

In this post, I describe that surprisingly simple integration in detail. My goal is to show how far one can go in Emacs with just a little customization effort, and to provide some useful insights in case you decide to experiment with any of this to streamline your specific workflow, too.

Orientation

  • I start with a simple Org capture template that prompts for an issue key (aka "ticket number"), then stores that key in a new, otherwise empty TODO heading as a JiraIssueKey property, then immediately finishes the capture.
  • Org mode offers a hook for processing the captured heading before it finalizes the capture. I add a function to that hook that pulls metadata for an issue key stored in the current heading from Jira's API, resets the heading's headline (its title) from it, and finally copies a bunch of the issue's details into the heading's properties.
  • Doing all the heavy lifting in a separate function has the advantage that I can run that function anytime, on any heading with a JiraIssueKey property. I use that to update existing headings (individually or in bulk) whenever I need to.

Capturing

If you've worked with Org capture templates before, this one will read pretty straight forward. It binds the i key to a template that prompts for the Jira issue key, then adds a new TODO heading with that property to ~/work.org under the top-level "Issues" heading. Note that I set the :immediate-finish flag, which means that capturing ends immediately after answering the prompt for the issue key.

(setq org-capture-templates
      '(("i" "Jira Issue" entry
         (file+headline "~/work.org" "Issues")
         "* TODO %^{JiraIssueKey}p"
         :jump-to-captured t
         :immediate-finish t
         :empty-lines-after 1)))

Post-processing the captured heading

In the code block below, I add a custom function fg/jira-update-heading to the hook I mentioned before. Org calls this function with point on the new TODO heading before it finalizes the capture.

(defun fg/jira-update-heading ()
  "Update heading for Jira Issue at point."
  (interactive)
  (when-let* ((pt (point))
              (issue-key (and (org-at-heading-p)
                              (org-entry-get pt "JIRAISSUEKEY"))))
    ;; TODO: Pull issue metadata, update headline and properties
    ))

(add-hook 'org-capture-before-finalize-hook #'fg/jira-update-heading)

Note that I declare this function as "interactive": that way, I can manually invoke it as a command to pull the latest issue metadata for the heading at point whenever I need to.

Note also that Org runs the above hook for every capture, not just the "Jira Issue" one. The fg/jira-update-heading function accounts for this by silently ending early in case point is not on an Org heading with a JiraIssueKey property.

Pulling issue metadata

I use nyyManni's straightforward, dependable jiralib2 package which provides "Jira REST API bindings to Emacs Lisp". The package covers many parts of Jira's API actually, so you could use it to grab an issue's comments, update the issue, etc., too. For my usecase, I'm only interested in fetchin an issue's metadata (API docs).

Setting up jiralib2 is simple. There are variables for the Jira host's URL, your username, and auth settings. I decide to use the "token authentication" method and create an API token in my Jira Account's settings2.

With the exception of the API token (which I keep in a secure location), I set everything up using local variables in the Org file to allow for varying settings in distinct Org files. I add this to the end of ~/work.org3:

# Local Variables:
# jiralib2-auth: token
# jiralib2-url: "https://example.atlassian.net"
# jiralib2-user-login-name: "fgrabo@example.com"
# End:

To test connectivity, I add this Org source block to pull an issue from Jira:

#+begin_src elisp
(jiralib2-get-issue "PRJ-1234")
#+end_src

Evaluating the block yields a data structure of nested association lists:

((key . "PRJ-1234")
 (fields
  (assignee
   (emailAddress . "fgrabo@example.com")
   (displayName . "Fritz Grabo"))
  (summary . "Fix typo in product logo")
  (description . "Actually, MegaCorp is spelled with a capital C")
  ;; Many, many more fields and details
  ))

The Emacs let-alist macro provides an elegant way to dig up values from arbitrary paths in nested association lists. Here's a quick example:

(let-alist (jiralib2-get-issue "PRJ-1234") .fields.assignee.displayName)
;; => Fritz Grabo

Updating headline and properties

With all the above out of the way, the complete fg/jira-update-heading function should be straight-forward to read:

(defun fg/jira-update-heading ()
  "Update heading for Jira Issue at point."
  (interactive)
  (when-let* ((pt (point))
              (issue-key (and (org-at-heading-p)
                              (org-entry-get pt "JIRAISSUEKEY"))))
    (let-alist (jiralib2-get-issue issue-key)
      ;; Update headline
      (let ((headline (format "%s %s" .key .fields.summary)))
        (message "Updating %s" headline)
        (org-edit-headline headline))
      ;; Update properties
      (cl-loop
       for (property value)
       on (list
           "JiraAssignee" .fields.assignee.displayName
           "JiraCreated" .fields.created
           "JiraIssueKey" .key
           "JiraIssueType" .fields.issuetype.name
           "JiraPriority" .fields.priority.name
           "JiraProjectKey" .fields.project.key
           "JiraReporter" .fields.reporter.displayName
           "JiraStatus" .fields.status.name
           "JiraSummary" .fields.summary)
       by #'cddr
       do (org-entry-put pt property value)))))

Here's what the result of using the capture template for PRJ-1234 looks like in the live Org file:

* Issues
** TODO PRJ-1234 Fix typo in product logo
   :PROPERTIES:
   :JiraIssueKey: PRJ-1234
   :JiraAssignee: Fritz Grabo
   :JiraCreated: 2022-05-08T10:49:56.963-0400
   :JiraIssueType: Task
   :JiraPriority: Blocker
   :JiraProjectKey: PRJ
   :JiraReporter: Elisabeth K.
   :JiraStatus: Ready
   :JiraSummary: Fix typo in product logo
   :END:

Bulk-updating Jira issues in an Org file

The last piece of the puzzle is a command to update all headings with a JiraIssueKey property in a buffer. Fortunately, alphapapa's remarkably useful org-ql package makes it dead easy to select all such headings and to run an arbitrary action on them:

(defvar fg/jira-heading-ql-query
  '(and (property "JiraIssueKey") (not (tags "ARCHIVE")))
  "Org-ql query to find headings for Jira issues.")

(defun fg/jira-update-headings ()
  "Update all headings for Jira issues in the current buffer."
  (interactive)
  (org-ql-select
    (current-buffer)
    fg/jira-heading-ql-query
    :action #'fg/jira-update-heading)
  (message "Done."))

Note that I filter out archived headings in the query. That's because I keep archived issues under an "Archived Issues" heading in the same file, and I don't bother updating them once they're archived. Note also that I pull the org-ql query out into a variable so I can override it using file-local variables if need be.

If you're so inclined, you could wire this function up to run on a timer, or when the file is modified. Myself, I invoke the command manually whenever I want updated details.

To make this a little easier, I place an external Org link to elisp:fg/jira-update-headings at the top of the file that runs the command when I click (or otherwise open) it.

Taking this further

With such easy means to add Jira issue details into an Org file, it's hard not to be tempted to do something with all that data.

Ideas include:

  • Defer the heading's TODO status from the issue's status4.
  • Fetch all the issues of the current sprint using jiralib2-jql-search, use a capturing column-view to render a quick dashboard.
  • Fetch like above, but use org-ql, ob-dsq and SQL queries to create reports like "story points left in sprint per assignee", etc. from Org heading properties.
  • Use minad's wonderful tempel package to expand the mention of an issue key into its <key and title>.

Closing thoughts

I am stunned to see how little code it takes to achive such a drastic impact on my daily work. "Such are the powers of the extensible, customizable text editor", I guess, and the possibilities that come with it.

I'm grateful to the authors and maintainers of Org mode, jiralib2 and org-ql, because really, I am just adding trivial glue code here to integrate packages that are showcases of good craftsmanship and that are built with extensibility in mind.

Finally, if you find any of this useful or have ideas on how to make it better, I'd love to hear from you. Thanks!

Footnotes:

1

If you're looking for a more apt integration with Jira, do check out the popular Ejira and org-jira packages, both of which come with an impressive list of features.

2

Go to https://id.atlassian.com, Account Settings, Security, Create and manage API tokens, Create API token.

3

If you follow along, note that you'll need to kill the buffer and revisit the file to apply these variables.

4

For example, I could set the heading's todo status to DONE when the issue's status moves to "In Production". In my workflow, though, I noticed that there's enough exceptions to the rule that automating this doesn't work for me. For instance, I often mark a heading DONE as soon as its issue goes to the release queue, but before it's "In Production". At the same time, I sometimes want to keep the heading in PROGRESS even after its issue moved to "In Production" because I want to verify an assumption after deploying to production before I close it out.
